Bajaj Boxer BM 150 Features and Specifications

Published: Saturday, September 3, 2011, 12:08 [IST]

« Previous

As we had said earlier, the new Bajaj Boxer 150 is aimed at the rural market in the slot previously occupied by the Yezdi and Rajdooth. Bajaj has made several changes to the engine to suit rural conditions. The chassis is more robust to take on uneven road conditions. Bajaj has added the electronic starter system.

Bajaj has added a twin fork telescopic suspension in the front while the rear suspension is a pair of shock absorbers. The Boxer rear suspension is SNS type suspension (Spring Inside Spring) which promises to deliver a smoother ride.

You can see the in detail technical specifications of the Boxer below. What we consider the clincher for the new Boxer 150 is its price. It remains to be seen if the Boxer will perform aas per the aspirations of Bajaj.

Bharat Bike : Bajaj Boxer BM150 Technical Specifications

Engine Type:
Single cylinder, 4 stroke, air cooled
Max. Power (Ps @ rpm) 12.01 @ 7500
Max. Torque (Nm @ rpm)12.26 @ 5000
Starting: Kick + Self

Suspension, Brakes & Tyres

Suspension
Front: 125mm fork travel telescopic
Rear 100mm wheel travel SNS

Brakes
Front 130mm Drum
Rear 130mm Drum

Tyre
Front 3.00 x 17, 45 P
Rear Tube type, 100/90 x 17, 55 P
Fuel tank capacity: l1 litres
Usable reserve: 2.5 litres

Dimensions

Overall Length (mm)2016
Overall Width (mm)740
Overall Height (mm)1055
Wheel base (mm)1285
Ground Clearance (mm)190
Saddle height (mm)803
Kerb weight (kg)123

Electricals

Battery12V / 2.5Ah or 5Ah
Head lamp 35/35W, HS 1
Tail / stop lamp 5/21W
